| Applicable Material | | Hard Materials | | Min D.O.C. | 2 mm |
| Application | | Ext. Round Face & Turn | | Depth of Cut Maximum (APMX) | 8 mm |
| Insert Style | RBGX | Min. Turning Feed (ft(min)) | 0.05 mm/rev |
| Corner Radius (RE) | 0 mm | Max. Turning Feed (ft(max)) | 0.4 mm/rev |
| Insert Size | 20 P20 | Clearance Angle Major (AN) | 5 Degrees |
| Insert Thickness (S) | 5 mm | Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 20 mm | Measurement Type | Metric |
| Cutting Edge Material | Ceramic | Body Material | Carbide |
| Grade | IN20 | Unit | M |
| Tool Type | Turn Ultra hard Inserts |
Product Features
| Family Description | Positive round ceramic inserts for machining cast iron and hardened steel | FamilyName | RBGX (CER) |
| COO | Japan | BrandName | Iscar |
Shipping Info
Name
Turning Indexable Inserts
FamilyName
RBGX (CER)
BrandName
Iscar
