SCD 090-045-100 AH5 IC903
Solid carbide drills for hard materials, drilling depth 5xD, without coolant holes.
| Drill Bit Size / Cutting Diameter (DC) | 9 mm | Tool Type | solid carbide Drills |
| Drill Bit Size / Cutting Diameter (DC) - Metric | 9 mm | Grade | IC903 |
| Length Group | 5xD | Measurement Type | Metric |
| Coating | AlTiN | Usable Length (LU) | 45 mm |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Length Chip Flute (LCF) | 63 mm |
| Application | | Drilling | | Overall Length (OAL) | 112 mm |
| Connection Diameter Machine Side (DCONMS) | 10 mm | Flute Count (NOF) | 2 |
| Coolant Supply Property (CSP) | External | Cutting Direction (HAND) | Right Hand |
| Number of Teeth | 2 | Body Material | Carbide |
| Shank Length (LS) | 46 mm | Connection Code Machine Side (CCMS) | Cylindrical |
| Shank Type | Round | Shank Diameter Tolerance (TCDMM) | h6 |
| Cutting Edge Material | Carbide | Unit | M |
Product Features
| Family Description | Solid carbide drills for hard materials, drilling depth 5xD, without coolant holes. | COO | Korea |
Shipping Info
Weight per item
0.1010
