| Shank Size (SS) | 25 | Coolant Supply Property (CSP) | External |
| Protruding Length (LPR) | 100 mm | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 25 mm | Measurement Type | Metric |
| Connection Diameter Workpiece Side (DCONWS) | 32 mm | Tool Type | Accessories and Devices |
| Connection Size (CSI) | MB32 | Unit | M |
Product Features
| Family Description | MB modular connection system with straight shanks | COO | Italy |
| Remarks | Verify that the weight of the entire tool assembly does not exceed the machine spindle's carrying capability |
Shipping Info
Weight per item
0.4040
