PENTA 24N100NF010RS IC908
Parting and precision grooving pentagonal inserts. Used for next to high shoulder applications.
| Cutting Width (CW) | 1 mm | Min. Grooving Feed (fg(min)) | 0.03 mm/rev |
| Corner Radius (RE) | 0.1 mm | Chip Breaker Type | K |
| Cutting Depth Maximum (CDX) | 1.8 mm | Tool Type | Parting & Grooving Inserts |
| Cutting Edge Material | Carbide | Measurement Type | Metric |
| Coating | TiAlN | Functional Width (WF) | 1.5 mm |
| Grade | IC908 | Body Material | Carbide |
| Cutting Direction (HAND) | Right Hand | Cutting Width Tolerance (+/-) (CWTOL) | 0.02 mm |
| Application | | Ext. Grooving | Ext. Grooving & Turning | Parting | | Insert Width (W1) | 3.76 mm |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Unit | M |
| Max. Grooving Feed (fg(max)) | 0.06 mm/rev |
Product Features
| Family Description | Parting and precision grooving pentagonal inserts. Used for next to high shoulder applications. | FamilyName | PENTA 24N-RS/LS |
| Remarks | For parting and grooving range, click on More Info. | BrandName | Iscar |
| COO | Israel |
Shipping Info
Weight per item
0.0110
Name
Parting Off Indexable Inserts
FamilyName
PENTA 24N-RS/LS
BrandName
Iscar
