TS S-A-L110-C12-T08-C
SHANK-MASTER stepped cylindrical shanks with threaded adaptation for interchangeable solid carbide milling heads
| Connection Diameter Machine Side (DCONMS) | 12 mm | Connection Thread Nominal Size Machine Side (THSZMS) | T08 |
| Overall Length (OAL) | 110 mm | Measurement Type | Metric |
| Body Length Maximum (LBX) | 60 mm | Body Material | Carbide |
| Tool Type | Cylindrical Shanks | Unit | M |
| Body Diameter (BD) | 11.5 mm |
Product Features
| Family Description | SHANK-MASTER stepped cylindrical shanks with threaded adaptation for interchangeable solid carbide milling heads | FamilyName | TS S-A |
| Remarks | Do not apply lubricant to the MULTI-MASTER threaded connection | BrandName | Iscar |
| COO | Israel |
Shipping Info
Weight per item
0.1830
Name
Solid End Mill Shanks
FamilyName
TS S-A
BrandName
Iscar
