Helical Interpolation Plunging & Recessing Rampdown Shouldering Slotting
See all 301 in this Product Family

‎ECI-7 250-500C030VF2 IC608

7 flute endmill with and without relieved neck, assorted radii and variable pitch for chatter dampening
FLASHSOLID
Item # ISC3411887
Brand: Iscar
Mfr#: 3411887
Quantity Available
loading...
Cutting Diameter (DC) 1/4″ Corner Radius (RE) 0.03″
Connection Diameter Machine Side (DCONMS) 1/4″ Ramping Angle Maximum (RMPX) 5 Degrees
Depth of Cut Maximum (APMX) 1/2″ Grade IC608
Overall Length (OAL) 2″ Tool Type Solid carbide non center cutting endmills 90°
Cutting Edge Material Carbide Maximum Feed per Tooth (fz(max)) 0.0022 ″/tooth
Coating AlTiCrSiN Minimum Feed per Tooth (fz(min)) 0.001 ″/tooth
Flute Count (NOF) 7 Coolant Supply Property (CSP) External
Shank Type Round Body Material Carbide
End Shape Corner Radius Decimal Equivalent 0.25″
Usable Length (LU) 1/2″ Measurement Type Inch
Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Unit I
Application | Helical Interpolation | Plunging & Recessing | Rampdown | Shouldering | Slotting |
‎ECI-7 250-500C030VF2 IC608

Product Features

Family Description 7 flute endmill with and without relieved neck, assorted radii and variable pitch for chatter dampening FamilyName ECI-7-VF
COO USA BrandName Iscar

Shipping Info

Name
Square & Corner Radius End Mills
FamilyName
ECI-7-VF
BrandName
Iscar
