| Thread Size | M6 | Cutting Edge Material | Carbide |
| Thread Pitch (TP) | 1 mm | Usable Length (LU) | 14 mm |
| Thread Standard | THFT | | Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 6 mm | Grade | IC908 |
| Cutting Diameter (DC) | 4.65 mm | Tool Type | Solid carbide thread mills |
| Overall Length (OAL) | 58 mm | Depth of Cut Maximum (APMX) | 2.55 mm |
| Flute Count (NOF) | 3 | Body Material | Carbide |
| Shank Type | Round | Connection Code Machine Side (CCMS) | Cylindrical |
| Coating | TiAlN | Thread Form Type (THFT) | M60 |
| Application | | Internal Thread Milling | | Unit | M |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
Product Features
| Family Description | Small diameter, solid carbide internal ISO profile threading mills. Designed for high cutting speeds, short cycle time and low cutting forces. Short threading contact for accurate and parallel thread. | COO | Israel |
Shipping Info
Weight per item
0.0230
