PICCO L 070.5-20 IC228
Back chamfering inserts for pre-parting operations.
| Connection Diameter Machine Side (DCONMS) | 5 mm | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Cutting Width (CW) | 1 mm | Application | | Pre Grooving with Chamfer | |
| Cutting Depth Maximum (CDX) | 1 mm | Tool Type | Solid Carbide Turn Tool |
| Overall Length (OAL) | 35 mm | Minimum Bore Diameter (DMIN) | 5 mm |
| Cutting Direction (HAND) | Left Hand | Front End Width (a) | 4.4 mm |
| Cutting Edge Material | Carbide | Measurement Type | Metric |
| Coating | TiCN+TiN | Body Material | Carbide |
| Grade | IC228 | Unit | M |
Product Features
| Family Description | Back chamfering inserts for pre-parting operations. | FamilyName | PICCO R/L 070 |
| COO | Germany | BrandName | Iscar |
Shipping Info
Weight per item
0.0100
Name
Solid and Brazed Groove/Turn & Part Off
FamilyName
PICCO R/L 070
BrandName
Iscar
