PICCO R016.0300-10N IC908
PICCO-JETCUT mini inserts with Coolant Holes for deep face grooving at Dmin 16/20 mm
| Connection Diameter Machine Side (DCONMS) | 8 mm | Front End Width (a) | 5.5 mm |
| Functional Length (LF) | 32 mm | Cutting Depth Maximum (CDX) | 9 mm |
| Cutting Direction (HAND) | Right Hand | Body Material | Carbide |
| Coating | TiAlN | Cutting Edge Material | Carbide |
| Grade | IC908 | Tool Type | Face Solid, Grooving &Turning grooving |
| Application | | Face Grooving | Int. Face Grooving | | Measurement Type | Metric |
| Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | | Unit | M |
Product Features
| Family Description | PICCO-JETCUT mini inserts with Coolant Holes for deep face grooving at Dmin 16/20 mm | FamilyName | PICCO-016/020-N (Face Grooving) |
| Remarks | All inserts have two coolant holes which may be used with coolant pressure up to 100 bars Solid tools are suitable for PICCO-N / PICCO ACE-N type holders only | BrandName | Iscar |
| COO | Germany |
Shipping Info
Weight per item
0.0190
Name
Solid Boring Bars
FamilyName
PICCO-016/020-N (Face Grooving)
BrandName
Iscar
