Ext. 80° Trigon 95° Approach Int. 80° Trigon 95° Approach
See all 39 in this Product Family

WNMG 080408-WG IC428

Double-sided trigon wiper inserts for high surface finish at high feed turning (0.3 to 0.6 mm/rev). Three to five times better surface finish compared to standard turning inserts at the same feeds.
ISOTURN
Item # ISC5593775
Brand: Iscar
Mfr#: 5593775
Please enter multiples of 10
Quantity Available
loading...
Applicable Material | Steel | Cast Iron | Hard Materials | Tool Type Turn Negative Inserts
Application | Ext. 80° Trigon 95° Approach | Int. 80° Trigon 95° Approach | Min D.O.C. 1 mm
Corner Radius (RE) 0.8 mm Depth of Cut Maximum (APMX) 3.5 mm
Insert Size 432-WG Min. Turning Feed (ft(min)) 0.1 mm/rev
Cutting Edge Length (L) 8.7 mm Max. Turning Feed (ft(max)) 0.5 mm/rev
Insert Thickness (S) 4.76 mm Clearance Angle Major (AN) 0 Degrees
Inscribed Circle Diameter (IC) 12.7 mm Chip Breaker Type WG
Cutting Edge Material Carbide Measurement Type Metric
Coating TiC+Al2O3 Body Material Carbide
Grade IC428 Unit M
WNMG 080408-WG IC428

Product Features

Family Description Double-sided trigon wiper inserts for high surface finish at high feed turning (0.3 to 0.6 mm/rev). Three to five times better surface finish compared to standard turning inserts at the same feeds. FamilyName WNMG-WG
Remarks For dimensions and tolerances, see more info. BrandName Iscar
COO Israel

Shipping Info

Weight per item
0.0112
Name
Turning Indexable Inserts
FamilyName
WNMG-WG
BrandName
Iscar
