| Applicable Material | | Steel | Stainless Steel | | Cutting Direction (HAND) | Right / Left |
| Application | | Chamfering & Bottom Deburring | Countersinking | Slanted Shoulder & Chamfer | | Cutting Edge Material | Carbide |
| Insert Length (INSL) | 9.52 mm | Tool Type | Single sided Inserts |
| Depth of Cut Maximum (APMX) | 5.6 mm | Minimum Feed per Tooth (fz(min)) | 0.12 mm/tooth |
| Insert Thickness (S) | 3.18 mm | Number of Cutting Edges | 4 |
| Insert Included Angle (EPSR) | 90 Degrees | Measurement Type | Metric |
| Coating | Uncoated | Body Material | Carbide |
| Grade | IC50M | Unit | M |
| Maximum Feed per Tooth (fz(max)) | 0.15 mm/tooth |
Product Features
| Family Description | Inserts for general use on 45° endmills. | FamilyName | SDMT-AD-N |
| COO | Israel | BrandName | Iscar |
Shipping Info
Weight per item
0.0034
Name
Milling Indexable Inserts
FamilyName
SDMT-AD-N
BrandName
Iscar
